panel light

[JpbInFL]

Working behind a panel a got a little rough I guess, and broke both tiny wires on one of these panel lights. Are they available. Are they anything common or special Hatteras only ?
My apologies. My subconcious said 'attach the picture' but then didn't connect with the action to do it...
96 42' CPMY



[drewread]

Happen to have a photo of the panel or light? Which veasel?



[Sadey]

I think Sams sells them, if not Les Henderson does. If you need his number PM me.



[Captain Ralph]

Henderson Marine Electronics

hatterassystemsmonitor.com



[Boatsb]

Carefully. He never met a system he didn't insist needed a rebuild. Quoted a friend $1600.00 to replace all the working parts on the board. It was a wire on a sensor. 0



[drewread]

Working behind a panel a got a little rough I guess, and broke both tiny wires on one of these panel lights. Are they available. Are they anything common or special Hatteras only ?
My apologies. My subconcious said 'attach the picture' but then didn't connect with the action to do it...
96 42' CPMY

If you pop that panel out, is there a model number on any of the lamp housings?



[drewread]

Thread 'Systems Monitor Panel Lights'

Aug 11, 2024

While troubleshooting my panel with Less Anderson, the panel guru, I mentioned my AUX light was burned out. He said he makes up those lights which he did. I don’t need all of them so if anybody needs lights, PM. He charged me $35 a piece plus shipping. I’ll pass that on to anybody who needs them.

• Sadey
• Replies: 2
• Forum: Parts Wanted & For Sale



[JpbInFL]

If you pop that panel out, is there a model number on any of the lamp housings?

I'll try and look again tomorrow - maybe take a magnifier with me. Man are those some tiny parts for these 71 year old eyes ! I also texted the Sams number to give that a shot.



[Boatsb]

Wow. I buy and use all kinds of indicator lights in customers panels. $3-7. Depending on size and voltage.

$35 is a bit punitive.



[Sadey]

I’m getting old, forgot about that. I’ll be at the boat tomorrow, I’ll see what I have left. Yes, Scott I thought it was a bit steep but he was helping out with some troubleshooting pro bono.



[JpbInFL]

Happen to have a photo of the panel or light? Which veasel?

Ok. Update. Turns out it's actually a tiny light bulb that is a friction fit from the back. And of course, I managed to break off two others as you can see, so now I really need a source or them.



[drewread]

Ok. Update. Turns out it's actually a tiny light bulb that is a friction fit from the back. And of course, I managed to break off two others as you can see, so now I really need a source or them.

EEK. Is it a 12V panel? If it was and the indicator lights were $35 a piece I'd have my calipers out to find an alternate option.



[SeaEric]

A 1996 42 CPMY is AFAIK a 12v boat. There's probably an LED option out there.



[SeaEric]

A 1996 42 CPMY is AFAIK a 12v boat. There's probably an LED option out there.

Maybe this? https://www.amazon.com/Gebildet-Pla...ix=dc+red+monitor+lights,aps,153&sr=8-13&th=1



[JpbInFL]

Maybe this? https://www.amazon.com/Gebildet-Plastic-Indicator-12V-24V-Mounting/dp/B0BDLH64TN/ref=sr_1_13?crid=45NGDCKVT15S&dib=eyJ2IjoiMSJ9.lsye2dkMDPoFD8jG6iq6-WDa35pGBXEybAfSVrdaiBsRaoX4Llzl28i4aOGhmr2njJXln6hyFxkfnFFZmDSH9AxIcS8umgJLtQHWzrfYvh28JLJnxc8_witiM3Aw_Zt6O7EoF_DTBvyoTw7vWFy2ATEk6H9nHhb9AAIyd3M1uMQhFc9sSVEpLots6u-VptlZ8PblYph-EbX7GaDrmb71YYZQQ-PcYvdDMXhrGQhOvyu8tH1587ldb9ZYdkdP9pq_B1ezscpv00w_XxVbgXUZQIiIfflMudmrI0pU-Jrb4-M.d6Wvi-nHu_VmbB0BxQqevvTxPTzWWabV4P8ocgJPas8&dib_tag=se&keywords=DC+red+monitor+lights&qid=1775418119&sprefix=dc+red+monitor+lights,aps,153&sr=8-13&th=1

Time to break out the calipers.. Thanks ! Still hoping maybe someone has 'been there/done it' and knows a perfect match already..



[Sadey]

I have a few bulbs available if you’re interested but they are 24V and won’t work in 12V or 32V systems if that’s what you have.



[rwaldrop13]

I found almost all the indicator lights independently and still have a spreadsheet. PM me rwaldrop13@gmail.com



[JpbInFL]

Update: Thanks to all here ! Every reply brought something to the table for me. I ended up ordering from that Amazon link (SeaEric), just the clear LEDs themselves (I mean, 50 for $8, worth a try) and they work great - slip right into the existing red lenses. Got my 2 basic engine not running' warning lights working right away. The challenge now is figuring out the remaining 'assignments' for the 3 pairs of loose wires I broke off while working in here. I have to say - that wiring in there - must be like 24 or 26 awg - is tricky to work with.
